Supertech Stainless Steel Inlet Valves (standard size 3 groove)

0056

£378.00

1 In stock

Qty


Product ref : AIVN-1103-12

PRODUCT OVERVIEW
Supertech Stainless Steel Intake Valves
Fits all 1.8T 20V engines and supplied as a complete set of twelve Supertech intake valves.
01
Fits all 1.8T 20V Engines
02
Complete set of twelve Supertech intake valves
03
Available in standard or +1mm oversized
04
Black Nitride Coating, Hardened Valve Tip & Undercut Stem
SUPERTECH MANUFACTURING
One-piece forged stainless steel construction
All Supertech stainless steel intake valves begin with a one piece forging, the valve head undergoes a two step forging process for excellent material grain flow. Each valve is then CNC machined to ensure exact final dimensions.

Next, another heat treatment and nitride hardening treatment for final stress relieving to ensure valve strength.

The valve receives one final grinding, followed by Supertech's patented Superfinishing of the entire surface. This ensures each valve is free of any imperfections and the dimensions are precise.
BLACK NITRIDE COATING
Surface hardening treatment
Supertech's Black Nitride Coating is a hardening treatment adhered to the base material at a microscopic level. The microhardness is higher than the underlying stainless steel material.

This keeps excellent ductility throughout the entire valve. Surface finish is smoother causing less friction between stem and guide, while the valve seat surface resulting in longer lasting valve head/seat interface.

The Nitride coating is a perfect match for any kind of valve seat such as nodular iron seats, steel powder metal seats, hard aluminum-copper seats or beryllium copper seats.

The Black Nitride anti-friction properties combat internal power loss due to valve-guide friction at higher engine speeds.
TECHNICAL SPECIFICATIONS
Head Diam
26.90mm (std)
27.90mm (+1.0)
Material
Stainless Steel 21-4N
Groove Type
Triple Groove
Length
105.10mm
Stem Diam
5.96mm
ENGINE APPLICATIONS
Compatible engines
VW - AEB
VW - 1.8T
Audi - AEB
Audi - 1.8T
