Garrett G25-585 GEN II Turbocharger 0.72 A/R V-Band

0244

£1971.36

Qty
GARRETT PERFORMANCE

Garrett G-Series II Turbocharger

The latest generation Garrett G-Series II Turbocharger

The Special Features
  • New compressor aerotechnology increases power and performance
  • Direct upgrade for Gen I customers as a complete turbocharger unit, supercore, or only with a cartridge/CHRA
  • G-Series II uses Gen I compressor and turbine housings.
  • Up to 10% higher flow volume compared to G-Series Gen I at maximum pressure ratio and maximum turbocharger speed.
  • Calibration required to utilize the increased flow volume for a power upgrade.
  • Increased efficiency at high flow rates
G-Series Gen I Features
  • High-flow compressor housing with optional connection for the speed sensor
  • Turbine wheel made of Mar-M (resistant up to 1050° C) with 15 to 20% more flow
  • Stainless steel turbine housing resistant up to 1050° C
  • Turbine housing with V-band inlet and V-band outlet
  • CHRA with V-band individually rotatable
  • Dual ceramic ball bearings
  • 4 water connection ports
  • Double sealing on the piston rings
  • Right and left rotating turbochargers available.
Turbocharger Specification
Power Range
Up to 585HP
Displacement
1.4 to 3.0l
Turbocharger Inlet Flange
V-Band
Turbocharger Outlet
V-Band
Compressor Side
Inlet 48.00mm
Outlet 60.00mm
Trim 65
A/R Value 0.70
Turbine Side
Flange Inlet V-Band
Flange Outlet V-Band
Inlet 54.00mm
Outlet 49.00mm
Trim 84
A/R Value 0.72
Wastegate Internal
G-SERIES II
Up to 585HP  |  1.4–3.0L  |  V-Band Inlet & Outlet

£1,971.36
